Excavator Hidraulik DEVELON DX225

PARAMETER PRODUK

  • Model: DX225
  • Operating Weight: 21,300 kg
  • Engine: DEVELON DL06 Six-Cylinder (National IV)
  • Rated Power: 127.9 kW / 1,800 rpm
  • Bucket Capacity: 1.05 m³
  • Max. Digging Depth: 6,592 mm
  • Max. Digging Height: 9,616 mm
  • Hydraulic Flow: 2 × 210.6 L/min
  • Track Width: 600 mm
Deskripsi
PERTANYAAN YANG SERING DIAJUKAN
Minta Penawaran

DESKRIPSI

DESKRIPSI PRODUK

The DX225 hydraulic excavator is powered by a DEVELON DL06 six-cylinder engine, meeting National IV emission standards. It is equipped with DPF and SCR aftertreatment systems, eliminating the need for urea and reducing operating costs. With high-altitude adaptability, the DX225 can work stably at 5,000 meters. Energy optimization via an electronically controlled hydraulic system and SPC3 intelligent control improves fuel efficiency by 10%, making it a highly efficient machine for modern construction and road repair projects.

STRUKTUR PRODUK

PARAMETER TEKNIS

ItemSpesifikasi
Model MesinDEVELON DL06
AspirationTurbocharged
Hydraulic System TypeElectronic Control
Max Hydraulic Flow2 × 210.6 L/min
Cylinders6
Bore100 mm
Stroke125 mm
Rated Power (DX225)127.9 kW / 1,800 rpm
Rated Power (DX225LC)129.4 kW / 1,900 rpm
Swing Drive MethodPenggerak Hidraulik
Reduction MechanismPlanetary Gear Reduction
Rem AyunWet Multi-Disc Brake
Kecepatan Ayunan10.4 rpm
Boom Cylinder120 × 85 × 1,263 mm
Arm Cylinder135 × 95 × 1,443 mm
Bucket Cylinder120 × 80 × 1,060 mm
Working Circuit Safety Valve350 / 370 kg/cm²
Travel Circuit Safety Valve350 kg/cm²
Swing Circuit Safety Valve280 kg/cm²
